Centrifugal pump DAB NOVA 180 M-A for gardens, pools, fountains, and other applications, head 4.8 m, flow 4.8 m³/h, power 0.19 kW

The DAB NOVA 180 MA centrifugal submersible pump is an ideal solution for draining and circulating clean water in gardens, decorative fountains, small pools and ponds.

With a maximum flow rate of 4.8 m³/h and a head of up to 4.8 meters , it provides efficient water pumping with low energy consumption.

Thanks to its compact design and light weight of only 4.6 kg , the pump is easy to carry and install even in tight spaces.

With a high degree of protection IP68 and the ability to submerge up to 7 meters , NOVA 180 MA guarantees reliable operation in various conditions.

Made in Italy by DAB , it combines European quality with durability and long service life.

Construction features of the pump:

• Pump housing, impeller, upper casing and suction grille made of waterproof technopolymer.
• Motor, rotor shaft and screws made of stainless steel.
• Three-layer O-ring seals preceded by an oil chamber.

Engine design features:

• Submersible, induction motor for continuous operation.
• Stator mounted in a hermetically sealed stainless steel housing covered by an upper body housing the wiring, microswitch and capacitor. Rotor mounted on oversized, greased, encapsulated bearings that ensure quiet operation and long service life.
• Built-in overheating and overload protection and capacitor, permanently in the circuit of the single-phase version. To protect the three-phase motor, it is recommended to use thermal overload protection that complies with current legislation.
• Manufactured according to CEI 2-3 and CEI 61-69 standards (EN 60335-2-41).
• Motor protection: IP68
• Insulation class: F

Technical data:

• Operating range: from 1 to 16 m3/h head up to 10.2 meters
• Liquid quality requirements: cloudy water without fibers.
• Liquid temperature range: from 0°C to +35°C for domestic use (EN 60335-2-41)
• Free passage of solid particles through the suction grille: 10 mm
• Minimum suction – NOVA 180: 77 mm, NOVA 200 - NOVA 180 NA: 8 mm, NOVA 300: 85 mm, NOVA 600 A:175 mm, NOVA 600 NA: 48 mm
• Maximum immersion depth 7 meters
• Maximum dry run time: 1 minute
• Installation: fixed or portable in vertical position.

DAB pump selection program
With DNA-Online you have a program for selecting DAB pumps and pump groups
