Wood cooker stove with back boiler MBS Thermo MAGNUM Right, 17kW
Estimated delivery
04.Dec.2024
See Shipping Policy
Free return
60 daysSee details
We accept payments
See details
Color : red
- Body made of sheet steel
- Combustion chamber lined with firebricks that accumulate heat and increase burning temperature.
- The combustion chamber is equipped with heat resistant ceramic glass that can withstand temperatures of up to 850°C.
- Hardened glass pane of the oven.
- Equipped with a thermometer.
- Cast iron grate.
- Door sealing made of fiberglass, does not contain asbestos
- Front damper for controlling the air supply
- Secondary air flap that increases the combustion temperature, efficiency and prevents fumigation of the glass.
- Metal door handles.
Achieving the desired heat output depends on:
- the selected fuel with the necessary caloricity and humidity
- its subsequent kindling and refueling
- the regulation of the primary and the secondary air
- the regulation of the draught
- the organizing of effective air heat exchange etc.
Characteristics | |
Oven position | Right |
Weight (kg) | 117.0000 |
Country of Manufacture | Serbia |
Dimension Depth (mm) | 660 |
Dimension Width (mm) | 1070 |
Dimension Height (mm) | 865 |
Thermometer | Yes |
Nominal thermal power (kW) | 17 |
Approximate heating surface (m²) | 90 |
Flue (mm) | 150 |
Exhaust Location | Top side |
Nominal heat output (kW) | 17 |
Recommended fuel | coal |
Approximate heating capacity (m³) | 243 |
Nominal water heating output (kW) | 9 |
Construction material | Steel |
Boiler capacity (L) | 11 |
Space heating output (kW) | 8 |
Overheating protected | No |
Ash and soot container | Yes |
Heating type | Hydro - Radiator |
Characteristics | Wood stove with water jacket, Stove, Oven |
Oven dimensions (Height, Width, Depth), mm | 265 x 350 x 465 |
Lining | Decorative lining |
Placement | Center |
Combustion chamber dimensions (Height, Width, Depth), mm | 280 x 230 x 370 |
Recommended system type | Open |
Flue damper | No |
